V Fold Paper Towel Making Machine Fully Automated With Auto
Transfer
Description:
This V Fold Paper Towel Making Machine Fully Automated With Auto
Transfer is used to manufacture interfold V fold paper towels, Z
fold, N fold and multi fold paper towels. It can auto transfer the
paper towel logs from the Z V fold paper towel interfolder to the
automatic v fold paper towel cutting machine and then auto transfer
the v fold paper towels to the automatic v fold paper towel packing
machine. The whole machine for the production of sheet paper towels
is fully automatic NO need worker to hand touch the tissue paper.
This full automated v fold paper towel machine with auto transfer
is the best v fold paper towel machine by China manufacturers now.
It is with the same speed and quality as Taiwan v fold paper towel
machine.
Advantage:
1 Machine for V fold Z fold N fold multi fold paper towels.
3 high speed up to 1000 sheet/min/lane
4 Full Automatic with auto transfer.
Quick details
1 Machine for production of Z V fold paper towels.
2 Fully Automatic with auto transfer
3 High Speed 1000 sheet / min.
7 Base Paper wide ranges:33-65g/m2 (single ply).
Technical parameters as below
| Model | ACE-V230-6L-AT |
| Function | V Fold Paper Towel Making Machine Fully Automated With Auto
Transfer |
| Folding speed | 1000 piece/min/lane * 6lanes = 6000 sheet/min, depending on the
paper quality and paper towel size. |
| Raw paper | 13-20g/m2 2-ply, 16-75g/m2 1-ply, wooden pulp paper or MG paper or
nonwoven airlaid. Other sizes please specify. |
| Jumbo roll size | ≤ 1260mm x Φ1500mm (Depends on your napkin size, customized) |
| Folding type | Inter folding Vacuum fold Z fold, N fold, multi fold, interfold, V fold |
| Point to point Lamination system | a. With 2 complete sets of point to point lamination units. b. The whole design is copied Italy design. c. Heavy chrome coating roll d. Micro-adjustment of nips between the steel roll e. Anilox roll for glue applicant. f. Controlled by cylinders g. Each lamination unit controlled by an independent reducer. When
the machine stops, the motor will start running to rotate the
anilox roll to prevent it getting dry. |
Control system automation | V Fold Paper Towel Making Machine Fully Automated With Auto
Transfer |
| Power | 7.5Kw for main motor 18.5KW for vacuum pump (3-phase AC380V 50Hz or customized) |
| Machine size | 6x2x2m |
| Weight | 6T |
| Videos and photos available. |
Below video of V Fold Paper Towel Making Machine Fully Automated
With Auto Transfer for your reference:
D. Folding unit
a. Automatic left-right stagger counting unit
b. Independent Floor standing wallboard structure (thickened full
steel plate support structure), to make sure the machine will NOT
vibrate when running at high speed. Other companies adopt half
steel frame for upper part and half steel part for lower parts,
which is weak structure.
f. This fully automatic paper towel machine is with auto transfer
system to auto transfer the paper towel logs to the automatic paper
towel cutting machine.
E. Full Embossing unit (New technology copied Italy)
a. With NEW Technology steel-to-rubber full embossing unit.
(Embossing pattern provided by the buyer or recommended by us.)
b. Controlled by level-type pneumatic system copied Italy design.
Most other companies’ machines embossing units are controlled by
screws or direct-pressing cylinders which make it very difficult to
control the web tension and the paper will stick to the rollers, if
you are not experienced enough, it will be big problem for you.
They mostly put the embossing units on the steel frame, when the
machine is running at high speed; it will definitely vibrate very
much.
H. Control system
a. Speed: about 1000 piece/min/lane x 6 lanes. Depends on paper
quality, workers etc.
b. Speed of production is controllable.
c. Main motor control by inverter
d. Automatic left-right stagger counting system, each stack of 100
pieces, 150pieces etc.
g. With Taiwan vacuum pump, about 18.5KW. (Taiwan brand)
h. Vacuum pump for adsorption (included in quotation.)
FAQ
Q.:Are you a factory or trading company?
A.: We are a factory and manufacturer.
Q.:How does your factory do regarding quality control?
A.:We pay much attention on quality controlling from very beginning
to the very end. Fully check and test takes before shipment.
Q.:Where is your factory located? How can I visit there?
A.:Our factory located at Dongguan, China.You can fly to Shenehn or
Guangzhou international airport directly. We will arrange to pick
you up.
Q.:What's service or guarantee can you offer?
A.: One year guarantee for key parts of machine, Machine installing
and worker training service, free technical support whole life.
Sample made by this V Fold Paper Towel Making Machine Fully
Automated With Auto Transfer for reference:
