Taiwan Design High Speed Automatic Interfold Facial Tissue Paper
Machinery With Steel To Steel Embossing.
Application
This ACE-V200-6L 6lines Taiwan Design High Speed Automatic Interfold Facial Tissue
Paper Machinery With Steel To Steel Embossing In China is with both full embossing unit and edge embossing unit. It is
mainly used to automatically fold, emboss, cut and count facial
tissue papers, soft drawing nylon pack facial tissue paper,
box-drawing facial tissue papers, pop up tissue paper napkin,
interleaved tissue paper, interfolded paper towel, V fold hand
towels, nonwoven airlaid tissue, and MG paper napkins etc.
all-in-one machine It adopts vacuum folding style. The mainly
function of this machine is to manufacture commercial tissue paper
products and away-from-home tissue paper products, easy-to-take one
by one plain, embossed and LOGO printed and laminated interfolded
dispenser napkins and V fold hand paper towels. It has 10 lanes
output and can run at very high speed up to 1000 sheets per minute
per lane. The jumbo roll width can be up to 2100mm. It has 4
unwinder jumbo roll stands which are driven by separate independent
reduction motor, not chain and belt. It is an ideal equipment to
manufacture high grade away-from-home customized embossed facial
tissue paper napkin products.
Advantage:
1 Machine for interfold box facial tissue paper and v fold paper
towel
2 With both full embossing and edge embossing.
3 high speed up to 1000 sheet/min/lane
5 Vacuum fold
6 Use vacuum pump
Quick details:
1 Cylinder cutoff size: 200mm/230mm/190mm etc.
3 with 6 - 10lines output.
4 Interfolded and V fold
5 Soft wrap tissue with soft nylon bags and duplex box.
Technical parameters as below
| Model | ACE-V200-16L |
| Output type | 6lines Taiwan Design High Speed Automatic Interfold Facial Tissue
Paper Machinery With Steel To Steel Embossing. |
| Folding speed | 1000 piece/min/lane * 6lanes, depending on the paper quality and
napkin size. |
| Raw paper | 13-20g/m2 2-ply, 16-45g/m2 1-ply, wooden pulp paper or MG paper or
nonwoven airlaid. Other sizes please specify. |
| Jumbo roll size | ≤ 2100mm x Φ1200mm (Depends on your napkin size, customized) |
| Napkin size | Open size: 200±2mm x 200/165/140mm Other size, please specify. Folded size: 100±2mm x 200/165/140mm Fixed cutoff size is 200m. Other size available, please specify. or
Customized. |
| Folding type | Interfold Vacuum fold 1/2 V fold. single fold |
| Embossing unit | 1- Steel to rubber. (Steel to steel is available.) 2- Embossing pattern can be any LOGO, brand name, flowers etc. 3- Embossing pattern can be customized by client or recommended by
us 4- Controlled by screws, mechanical pressing type. Cylinder type is optional. 5- With edge embossing units. |
| Point to point Lamination system | Lamination system is optional. a. With 2 complete sets of point to point lamination units. b. The whole design is copied Italy design. c. Heavy chrome coating roll d. Micro-adjustment of nips between the steel roll e. Anilox roll for glue applicant. f. Controlled by cylinders g. Each lamination unit controlled by an independent reducer. When
the machine stops, the motor will start running to rotate the
anilox roll to prevent it getting dry. |
| Tension control | Speedless Tension control unit to fit the machine for paper of
different quaity and different gsm. With automatic web guiding system. With automatic web tension control system. |
| Counting | Automatic counting unit |
| Emergent stop | Emergent stop unit to inspect any paper breaks, paper jams. |
| Paper feeding | Synchronizer for feeding paper |
| Power | 7.5Kw for main motor 18.5KW for vacuum pump (3-phase AC380V 50Hz or customized) |
| Machine size | 6x2x2m |
| Weight | 6T |
| Videos and photos available. |
B. Product size
a. Unfolded size: 200±2mm x 200/165/140mm Other size, please
specify.
b. Folded size: 100±2mm x 200/165/140mm
c. Fixed cutoff size is 200m. Other size available, please specify.
d. The cutting length is adjustable. Could be 190mm, 200mm etc..
e. Folding type: V fold, interfold and Vacuum folding type.
G. Printing Section (advanced design.)
1. With 2 colors flexo-graphic printer section.
2. Printing unit with driven by timing belts to make printing more
precise.
3. Simple and easy adjustment of horizontal and longitudinal
registration by turning hand wheel.
4. With automatic printing roller disconnection device during
machine stop. If the machine stops, the roller will automatically
disconnect with the printing unit, controlled by pneumatic system.
6. Both sides of Anilox roll & Rubber roll with buffer for
anti-spill cover to stop the ink spilling out of the ink tank and
spraying somewhere.
F. Laminating unit
a. With 2 sets of lamination units.
c. Heavy chrome coating roll
d. Micro-adjustment of nips between the steel roll
e. Anilox roll for glue applicant.
f. Controlled by cylinders
g. Each lamination unit controlled by an independent reducer. When
the machine stops, the motor will start running to rotate the
anilox roll to prevent it getting dry.
H. Control system
a. Speed: about 1000 piece/min/lane x 2 lanes. Depends on paper
quality, workers etc.
b. Speed of production is controllable.
c. Main motor control by inverter
d. Automatic left-right stagger counting system, each stack of 100
pieces, 150pieces etc.
e. Machine will automatically stop if paper break or paper jams.
f. Power: about 5.5KW for main motor 3-phase AC380V 50HZ or
customized.
g. With Taiwan vacuum pump, about 11KW. (Taiwan brand)
h. Vacuum pump for adsorption (included in quotation.)
FAQ
Q: Are you trading company or manufacturer
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is
60-90 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay
the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30%
T/T in advance ,balance before shippment.
Finished products by this Taiwan Design High Speed Automatic Interfold Facial Tissue Paper
Machinery With Steel To Steel Embossing In China:
