    Auto Wrap Facial Tissue Packing Machine 25Pack/Minute Fault Tracked With Monitoring System

    Ask Lasest Price
    Brand Name : ACE
    Model Number : ACE-VBM-A
    Certification : CE
    Price : $20000 - 60000/set
    Payment Terms : L/C, , T/T
    Supply Ability : 10 set /month
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Auto Wrap Facial Tissue Packing Machine 25Pack/Minute Fault Tracked With Monitoring System

    Fully Automatic Facial Tissue Paper Autowrap Machine 3-24 Bag/Bundle

    Application of this Fully Automatic Facial Tissue Paper Autowrap Machine 3-24 Bag/Bundle:

    This Fully Automatic Napkin Tissue Bundle Packing Machine 3-24 Bag/Bundle is an ideal machine to pack hygienic tissue rolls in the format single row and double rows of 2 * 4 bags (8 bags), 2 * 5 bags (10 bags) , 2 * 6 bags (12 bags) etc. It can greatly increase the production and save lots of labor. It is an economical good price tissue paper packing machine for small scale tissue converting factory.


    Main features:

    1. adopt PLC and servo motors to drive the products feeding, overturn, counting, bag feeding, bag opening, bagging, sealing automatically.

    2. bagging and sealing: adopt the mound negative pressure type bagging and sealing to keep the products shape nicely.

    3. Fault tracked and warmed: the fault will be showed on the touch screen and tracked the reason to make easy to solve the fault.

    4. monitoring system: bags controlled, product checking to keep the machine won’t pack without products;and the checking system help to output the defective goods. In case that the bag can not open, machine will automatic stop. In case the bag is fault and cannot open, the bag will output automatically.


    Advantage:

    1 machine to pack both napkin paper and facial tissue.

    2 fully automatic.

    3 high speed up to 25 pack/minute.

    4 Save labor costs.

    6 Easy operation.


    Technical parameter of Fully Automatic Napkin Tissue Bundle Packing Machine 3-24 Bag/Bundle:


    Machine modelACE-VBM-A
    Packing speed10-25 packs/min
    Max bundle bag length420mm
    Finished bundle bag width130-420mm
    Finished bundle bag height90~105mm
    Bundle bag max length640mm
    Bundle bag packing type3,4,5,6,8,10bags/bundle
    Bundle bag materialPre-made M bag with air outlet hole(dia 5-6mm),the thickness is 40-60μm, opp, cpp, pe double side sealing film
    Pre-made bag qty2 bag base for changing and each one can hold 300-400 pcs
    Machine out-dimension4900×2900×1920 mm
    Machine power supply380V±10%,50Hz±5%
    Air supply0.6~0.7Mpa ,330L/min
    Machine weightAbout 2500kg
    Noise<80dB
    Total power12.56Kw

    Machine main parts list of this Fully Automatic Napkin Tissue Bundle Packing Machine 3-24 Bag/Bundle.

    No.NameBrands
    10BreakerLiangxin
    11Solid relayCrydom
    12Liner guiderHIWIN
    13HMIWeinview
    14Fibre sensorKeyence
    15Temp controllerYuyao
    16Power switchMEAN WELL
    17CylinderAirtac
    18Solenoid valveAirtac
    19Fanzhangao
    20Planetary reducerXingxing
    21Gear motorHengxing

    Sample of finished product by Fully Automatic Facial Tissue Paper Autowrap Machine 3-24 Bag/Bundle.

    Facial Tissue Paper Autowrap Machine
