Fully Automatic High Speed Log Accumulator For Toilet Tissue Paper
Roll
Application of this
This ACE-LA100 high speed Fully Automatic Log Accumulator For Toilet Tissue Paper Roll is a first-in-first-out design used as a buffer of stored logs
between the rewinder line and downstream equipment to help maintain
consistent production during process upsets and changeovers. It is a log accumulator for toilet paper, kitchen towel, JRT, maxi
roll, jumbo roll tissue and also nonwoven airlaid rolls
automatically load the toilet paper log and unload the tissue paper
log to the cutting machine like log saw cutting machine or
automatic band saw. It can be used as a storage between the toilet
paper kitchen towel rewinder machine and the log saw machine.
Quick details:
1 Mother roll width 1200mm – 4000mm
2 A log accumulator for toilet paper kitchen towel jumbo roll
tissue and nonwoven airlaid rolls.
3 Fully automatic.
4 High speed
5 Can connect to rewinder machine and logsaw cutting machine
Technical parameters of this Fully Automatic Log Accumulator For Kitchen Towel Paper Roll is as below
| Model | ACE-LA100 Log Accumulator |
| Machine name | High Speed Log Accumulator For Toilet Tissue Paper Roll |
| Mother roll width(mm) | 1300 | 1800 | 2000 | 2200 | 2400 | 2600 | 2800 | 3000 | 4000 | Customized |
| Log width | Up to 3000mm or customized |
| Machine speed | about 20 log/minute. |
| Raw material | toilet paper kitchen towel maxi roll JRT roll jumbo toilet paper MG paper nonwoven roll or airlaid roll. Other sizes please specify. |
| Log diameter | 90-140mm. or 150 - 250mm or customized. |
| log accumulator storage capacity | 100 logs or customized 200 lgs or 60 logs etc. |
| Automatic | fully automatic to work between the rewinder machine and the log
saw cutting machine. |
| Point to point Lamination system | a. With one complete sets of point to point lamination units. b. The whole design is copied Italy design. c. Heavy chrome coating roll d. Micro-adjustment of nips between the steel roll e. Anilox roll for glue applicant. f. Controlled by cylinders g. Each lamination unit controlled by an independent reducer. When
the machine stops, the motor will start running to rotate the
anilox roll to prevent it getting dry. |
More specification of this High Speed Log Accumulator For Toilet Tissue Paper Roll.
1) The same safety devices as the other machines.
2) Automatic running, first log in, first log out, with automatic
transfer into the log saw.
3) With 100 logs storage capacity, with two unloading system.
(storage quantity can be confirmed.)
4) It will receive the logs from the rewinder, and discharge them
into two saws, at the speed up to 20 logs/min.
5) Heavy frames, easy to assembly and disassembly to fit the
container
6) Plastic trays for log support
7) Log length: 2800mm. (or customized.)
8) Power: 4KW
9) Machine size: 3000x3500x3600mm
10) Machine weight: 2500kg
FAQ of this High Speed Log Accumulator For Toilet Tissue Paper Roll:
Q1: Why choose our machine?
A: 1. High quality with competitive price.
2. 24 Hours Online Service (MSN, SKYPE, TRADEMANAGER)
3. 12 Months quality warranty
4. Engineers available to service machinery overseas
Q2: How to operate and maintain the machine?
A: 1. We will provide a professional and detailed USER GUIDE to you with the machine;
2. We also provide abroad technical training service.
Q7: why kitchen paper need to glue.(lamination)
A7: 1. After embossing, two plies of paper will be laminated by
glue, and the paper will be even
fluffier than normal embossing.
2. Laminated paper could absorb more water more quickly, make the
paper more useful
during cleanning.
3. Also, we could use color glue to make the paper more beatiful
and attractive.
Welcome to contact us to find out more details of this Fully
automatic Facial tissue paper packing machine.
